Wing Knob Camlocks

Wing Knob Camlocks are ideal for cabinet and enclosure applications; featuring an ergonomic Lock knob. Our Wing Knob Camlocks are comprised of a Die Cast Zinc Plated Steel lock mechanism and a black powder coated Die Cast Zinc Knob.

Our range of Wing Knob Camlocks have an IP Rating of IP54; protecting them from dust and splashing water. Die Cast Zinc Plated Steel is hardwearing and has a strength of 48,000 PSI; making our Wing Knob Camlocks ideal for heavy duty use.

Wing Knob Camlocks have a quarter turn locking mechanism which requires the user to turn the Knob 90° to lock and unlock the application.

These Camlocks are stocked in two different designs:
• With Lock – Supplied with a locking mechanism and matching Standard Key
• Without Lock – Supplied without a locking mechanism

Key Product Features:
• IP54 Rating
• RoHS, REACH, Conflict Minerals and California Prop 65 compliant
• Strength of 48,000 PSI
• Ergonomic Lock Knob

Need help choosing the perfect Camlock for your project? Give us a Call 01233 713581 or Email Us
