Square Key Camlocks

Square Key Camlocks have a quarter turn mechanism which works by directing the Cam away from the contact point. This locking mechanism requires the user to turn the Knob 90° to lock and unlock the application. Square Key Camlocks are adaptable and ideal for a variety of applications such as cabinets, doors, drawers, access panels and secure enclosures.

Our range of Wing Knob Camlocks have an IP Rating of IP54; protecting them from dust and splashing water.

Our Square Key Camlocks are made from Die Cast Zinc Plated Steel. Die Cast Zinc Plated Steel is hardwearing and has a strength of 48,000 PSI; making our Square Key Camlocks ideal for heavy duty use.

Each of our Square Key Camlocks are supplied with the matching Square Key counterpart; allowing for immediate use. Square Key Camlocks require a rare Square Key type in order to gain access to the application; increasing security and limiting access.

Key Product Features:
• IP54 Rating
• RoHS, REACH, Conflict Minerals and California Prop 65 compliant
• Strength of 48,000 PSI
• Rare key type

Need help choosing the perfect Camlock for your project? Give us a Call 01233 713581 or Email Us
