Double-Bit Key Camlocks

Double-Bit Key Camlocks have a quarter turn mechanism which works by directing the Cam away from the contact point. This locking mechanism requires the user to turn the knob 90° to lock and unlock the application. Double-Bit Key Camlocks are adaptable for applications such as cabinets and enclosures.

Our range of Double-Bit Key Camlocks have an IP Rating of IP54; protecting them from dust and splashing water.

These Camlocks are stocked in two different materials:
• Chrome Plated Die Cast Zinc ; Chrome Plated Die Cast Zinc is hardwearing and has a strength of 48,000 PSI
• A2 Stainless Steel; Stainless Steel is corrosion resistant and has a temperature range of between -196 to 300°C

Our Double-Bit Key Camlocks are not supplied with the matching Double-Bit Key counterpart but are available to purchase separately. Double-Bit Keys are a rare key type; increasing security and limiting access.

Key Product Features:
• IP54 Rating
• RoHS, REACH, Conflict Minerals and California Prop 65 compliant
• Strength of 48,000 PSI
• Temperature range of between -196 to 300°C
• Corrosion resistant
• Rare key type
